178858 - Scraper Knives HW with 1 cutting edge and chamfer
Product
Drawing
-
- Tungsten Carbide [HW]
Technical data
Description
Machine / Application
- machines IMA units 181.91 and 0.6126 (BAZ) with 30 mm width, unit 08.50 with 55 mm width
Design
- cutting material: HW
- HL Solid 20 for wood-based panels, hard and soft woods
Advantages
Notes
| Feature | Value | |
|---|---|---|
| Chamfer∡ = Chamfer angle | 15 [°] | |
| B = Width | 30 [mm] | |
| H = Height | 22.5 [mm] | |
| S = Thickness | 3 [mm] | |
| Ø d = Bore diameter | 5,8 [mm] | |
| LEUCODUR = Cutting material | HL Solid 20 | |
| PU = Packing unit | 2 [pc.] | |
| L/R = cutting direction | R | |
| L = Delivery Status | ||
|
Dimensions entered are not listed?
available from stock |
||
Spare parts / accessories
| Product picture | Description | Design | Ident-No. | ||
|---|---|---|---|---|---|
|
Countersunk Screws - with Torx | M5x10 T20 D=Ø10 | 171236 | ||
|
available from stock |
|||||
